IBM iSeries 800 Hardware Problem Analysis And Isolation

Bus number
Multi-adapter
bridge
number in
DSA
Multi-adapter
bridge function
number in DSA Item DSA points to:
Position label and PCI
data width
xxxx (assigned by LIC) 2 0 PCI IOP or IOA card C11 (64 bit/INS)
xxxx (assigned by LIC) 2 2 PCI IOP or IOA card C12 (32 bit)
xxxx (assigned by LIC) 2 3 PCI IOP or IOA card C13 (32 bit)
xxxx (assigned by LIC) 2 4 PCI IOP or IOA card C14 (64 bit)
xxxx (assigned by LIC) 2 6 PCI IOP or IOA card C15 (64 bit)
xxxx (assigned by LIC) 2 F PCI IOP or IOA card CB1
Table 8. Card positions for FC 5075 I/O Expansion Tower
Bus number
Multi-adapter
bridge
number in
DSA
Multi-adapter
bridge function
number in DSA Item DSA points to:
Position label and PCI
data width
xxxx (assigned by LIC) 1 0 Embedded IOP CB1
xxxx (assigned by LIC) 1 1 PCI IOP or IOA card C01 (32 bit)
xxxx (assigned by LIC) 1 2 PCI IOP or IOA card C02 (64 bit)
xxxx (assigned by LIC) 1 4 PCI IOP or IOA card C03 (64 bit)
xxxx (assigned by LIC) 1 6 PCI IOP or IOA card C04 (64 bit)
xxxx (assigned by LIC) 1 F Multi-adapter bridge CB1
xxxx (assigned by LIC) 1 0 PCI IOP or IOA card C05 (64 bit)
xxxx (assigned by LIC) 1 2 PCI IOP or IOA card C06 (64 bit)
xxxx (assigned by LIC) 1 4 PCI IOP or IOA card C07 (64 bit)
xxxx (assigned by LIC) 1 6 PCI IOP or IOA card C08 (64 bit)
xxxx (assigned by LIC) 1 F Multi-adapter bridge CB1
Table 9. Card positions for FC 5095 I/O Expansion Tower
Bus number
Multi-adapter
bridge
number in
DSA
Multi-adapter bridge
function number in
DSA Item DSA points to:
Position label and
PCI data width
xxxx (assigned by LIC) 2 0 and 1 PCI
IOP
C01
xxxx (assigned by LIC) 2 2 and 3 PCI
IOP or
IOA card
C02
xxxx (assigned by LIC) 2 4 and 5 PCI
IOP or
IOA card
C03
xxxx (assigned by LIC) 2 6 and 7 IOA card C04
xxxx (assigned by LIC) 2 F Multi-adapter bridge CB1
xxxx (assigned by LIC) 2 Not used Not used C05
Analyze hardware problems 71
