IBM iSeries 810 Hardware Problem Analysis And Isolation

1. Select Manual mode and perform an IPL to DST (see Performing an IPL to DST in the iSeries
(TM)
Service Functions information).
Does the Disk Configuration Error Report display appear?
v Yes: Does a ″Load source failure″ message appear in the list?
– Yes: Continue with the next step.
– No: The system is now using the correct load-source.
This ends the procedure.
v
No: The system is now using the correct load-source.
This ends the procedure.
2.
Select option 5, press F11, and then press Enter to display details.
The load-source type, model, and serial number information that the system needs is displayed on the
console.
Is the load-source disk unit (displayed on the console) attached to an MSIOP that cannot be used for a
load-source?
v Yes: Continue with the next step.
v No: The load-source disk unit is missing. Go to step 1 (See page 124) for cause code 0002.
3.
Is the system configured for remote load-source protection?
v No: Move the load-source disk unit to the load-source MSIOP.
This ends the procedure.
v Yes: Go to Recover remote load source.
001C:
The disk units that are needed to update the system configuration are missing.
Perform an IPL by doing the following:
1. Select Manual mode on the control panel.
2. Perform an IPL (see Initial Program Load (IPL) Information in the iSeries
(TM)
Service Functions
information) to determine the cause of the problem.
This ends the procedure.
001D:
1. Is the Disk Configuration Attention Report, or the Disk Configuration Warning Report displayed?
v Yes: Continue with the next step.
v No: Ask your next level of support for assistance.
This ends the procedure.
2.
On the Bad Load Source Configuration message line, select 5, and press Enter to rebuild the
load-source configuration information. If there are other types of warnings, select option 5 on the
warnings, and correct the problem.
This
ends the procedure.
001E:
The load-source data must be restored.
Go to Recovery procedures.
This
ends the procedure.
001F: Licensed Internal Code was installed on the wrong disk unit of the load-source mirrored pair.
The system performed an IPL on a load source that may not contain the same level of Licensed Internal
Code that was installed on the other load source. The type, model, and address of the active device are
displayed in words 4-7 of the SRC.
1. Choose from the following options:
Analyze hardware problems 131
