T
able
1.
Final
assembly
-
Models
270,
800,
and
810
Index
Part
numbers
Units
Description
1
24L1609
1
Cover,
processor
/
memory
/
CEC
2
24L1551
1
Processor
/
memory
/
CEC
assembly
3
75G2878
8
Screw
,
M3.5
x
8mm
Analyze
hardware
problems
369
380
382
