Table 1. Final assembly — FC 5075
Index Part number Units Description
1 24L1592 1 Op panel
2 24L1730 2 Air moving device assembly
3 NONUM 1 Cage assembly disk unit
4 75G2878 4 Screw, M3.5 x 8mm
4A 04N3392 2 Screw, M3.5 x 35mm
5 24L1827 1 EMC shield, disk unit
5A NONUM AR Disk unit assembly. See the
Type, model, and part
number list.
6 21P6417 AR Power supply. See the
Type, model, and part
number list.
Analyze hardware problems 465
