IBM iSeries 820 Hardware Problem Analysis And Isolation

Table 17. Memory information for Models 800, 810, 825, 870, and 890
Model
Processor
feature code Memory CCIN Location
800 and
810
7400 through
7412
3092, 3093, 3094, 3095, 3096 A through H
810 7428 and
7430
3022, 3024, 3025, 3026, 3027, 3029 M01
825 All 3041, 3042, 3043, 3044, 3045, 3046, 3047 C13, M01, and M02
(Slots A through H)
870, 890 All 3015, 3016, 3017, 3018, 3020, 3021, 3035, 3036,
3037, and 3038, 3621, 3622, 3624, 3625
M01, M02, M07, M08, M17, M18,
M24, M25
Table 18. System backplane information for Models 800, 810, 825, 870, and 890
Model Unit reference code Processor feature code Backplane type Location
810 x001 7428, 7430 282F MB1
810 x001 7410, 7412 25F0 MB1
800, 810 x001 7400 25B9 MB1
800, 810 x001 7407, 7408, 7409 25BA MB1
825 4009, 8009 or C009 All 289C (4-way) or 289D
(6-way) (Backplane extender
- right side)
MB2
825 400A, 800A or C00A All 28B3 (Backplane extender -
left side)
MB1
825 4002, 8002 or C002 All 25Ca CB1
870, 890 4002, 8002 or C002 All 25C0 MB1
Table 19. Clock card information for Models 870 and 890
Model
Unit reference
code Processor feature code Clock card type Location
870, 890 x001 All 25C1 M15
Table 20. Cache card information for the Models 870 and 890
Unit reference code FRU description / CCIN Location
xD00 L3 cache card / 25F1 M27
xD01 L3 cache card / 25F1 M28
xD02 L3 cache card / 25F1 M22
xD03 L3 cache card / 25F1 M20
xD04 L3 cache card / 25F1 M29
xD05 L3 cache card / 25F1 M06
xD06 L3 cache card / 25F1 M13
xD07 L3 cache card / 25F1 M23
xD08 L3 cache card / 25F1 M05
xD09 L3 cache card / 25F1 M04
Analyze hardware problems 317
