IBM iSeries 820 Hardware Problem Analysis And Isolation

2. Determine the tower type where the failing component is located and exchange the FRU indicated
using the links to the service information for that FRU.
Table 1. Name of FRU to exchange for symbolic FRU SIADPCD
System model, tower,
expansion unit, or machine
type Name of FRU to exchange
Link to failing component service
information (CCIN, Locations diagram,
remove and replace procedure)
Models 830 and SB2 Base I/O
Tower (FC 9074)
HSL I/O bridge card See Locations - Models 830/SB2 system unit
with FC 9074 base I/O tower
Models 840 and SB3 Base I/O
Tower (FC 9079)
HSL I/O bridge card See Locations - Models 840/SB3 system unit
with processor tower and FC 9079 base I/O
tower
Models 870 and 890 HSL I/O bridge card See Locations - Models 870 and 890 with an
FC 9094 Base I/O Tower
FC 5074 Expansion I/O Tower HSL I/O bridge card See Locations - FC 5074 I/O Tower
FC 5078, FC 0578 Expansion
I/O Unit
HSL I/O bridge card See Locations - FC 5078, FC 0578 Expansion
I/O Unit
FC 5079 (1.8m Expansion I/O
Tower)
HSL I/O bridge card See Locations - FC 5079 I/O Tower
FC 5088, FC 0588 Expansion
I/O Unit
HSL I/O bridge card See Locations - FC 5088, FC 0588 Expansion
I/O Unit
FC 5095, FC 0595 Expansion
I/O Tower
HSL I/O bridge card See Locations - FC 5095, FC 0595 Expansion
I/O Tower
External xSeries Server Integrated xSeries Adapter Card See Locations - Integrated xSeries adapter card
(IXA)
This ends the procedure.
SI_CARD
For use by authorized service providers.
SI_CARD: high-speed link controller card.
The failing component is the network interface controller (NIC) card in the system unit.
Use the system model and the table below to determine the service information for the failing component.
System model Name of FRU to exchange Link to failing component service
information (CCIN, locations diagram,
remove and replace procedure)
Models 870 and 890 Network Interface Controller Locations - Models 870 and 890 with an
FC 9094 Base I/O Tower
Models 830 and SB2 Network Interface Controller Locations - Models 830/SB2 system unit
with FC 9074 base I/O tower
Models 840 and SB3 Network Interface Controller Locations - Models 840/SB3 system unit
with processor tower and FC 9079 base
I/O tower
This ends the procedure.
Analyze hardware problems 447
