The system processor has detected an error on the HSL port. The error was found during an IPL, and is
preventing the system from finishing the IPL. The error is on the load source or flash source HSL Bus.
1. Use the information in the Location of failure column in Table 1. below, and the information from
Locations and Addresses to determine the physical mapping of the information from the Location
column.
2. Check the cabling and connections from the failing port. Follow the procedure in Symbolic FRU
“BUSCBL1, BUSCBL2, BUSCBL3, or BUSCBLx” on page 292.
3. If checking cables and connections does not correct the problem, replace the HSL connection in the
given location.
4. Choose from the following options:
v For Models 800 and 810: See Locations - Models 800 and 810. All errors are on the A0-A1 HSL
port. If checking the cables does not correct the problem, the field replaceable unit (FRU) to replace
is the System unit backplane, CCIN 25F0, 25B9, 25BA, or 282F.
v For Model 825: See Locations - Model 825.
– For SRCs of the form B428 xB0x, the failing item is the HSL Card in position C09.
– For SRCs of the form B428 xB1x, the failing item is the HSL Card in position C08.
– For SRCs of the form B428 xB2x, the failing item is the HSL Card in position MB1.
v
For Models 870 and 890: See Table 1. below, and Locations - Models 870 and 890.
Table 1. Failure locations for Models 870 and 890
System reference code Location of failure
B448 xB00 M41 port A0
B448 xB01 M41 port A1
B448 xB02 M41 port B0
B448 xB03 M41 port B1
B448 xB10 M40 port A0
B448 xB11 M40 port A1
B448 xB12 M40 port B0
B448 xB13 M40 port B1
B448 xB14 M40 port C0
B448 xB15 M40 port C1
B448 xB16 M40 port D0
B448 xB17 M40 port D1
B448 xB20 M30 port A0
B448 xB21 M30 port A1
B448 xB22 M30 port B0
B448 xB23 M30 port B1
B448 xB24 M30 port C0
B448 xB25 M30 port C1
B448 xB26 M30 port D0
B448 xB27 M30 port D1
B448 xB30 M39 port A0
B448 xB31 M39 port A1
B448 xB32 M39 port B0
B448 xB33 M39 port B1
Analyze hardware problems 445
