3. Refer to the “Card positions” on page 65 in this page to search for the bus number, the multi-adapter
bridge number, and the multi-adapter bridge function number that matches the system unit or I/O tower
type where the bus is located.
Table 2. DSA breakdown
The DSA format is: BBBB Ccbb (bb is not used). BBBB=Bus number, Cc=Card identifier
Bus number The bus type is:
C = The multi-adapter bridge
number
c = The multi-adapter bridge
function number
0001 PCI 1 0 through 7
0001 PCI 2 0 through 7
0001 PCI 7 0
0002 through 0003 PCI 1 0 through 7
0002 through 0003 PCI 2 0 through 7
0004 through 0016 SPD Logical card number. See the
Bus Overview section in the
Migrated Expansion Tower
Problem Analysis, Repair and
Parts manual on the V5R1
Supplemental Manuals web site
.
Logical card number. See the Bus
Overview section in the Migrated
Expansion Tower Problem
Analysis, Repair and Parts manual
on the V5R1 Supplemental
Manuals web site .
0017 through 00FF PCI 1 0 through 7
0018 through 00FF PCI 2 0 through 7
0100 HSL loop number 256
(decimal)
N/A N/A
0101 HSL loop number 257
(decimal)
N/A N/A
0102 HSL loop number 258
(decimal)
N/A N/A
0103 HSL loop number 259
(decimal)
N/A N/A
0104 HSL loop number 260
(decimal)
N/A N/A
0105 HSL loop number 261
(decimal)
N/A N/A
0106 HSL loop number 262
(decimal)
N/A N/A
0107 HSL loop number 263
(decimal)
N/A N/A
0108 HSL loop number 264
(decimal)
N/A N/A
0109 HSL loop number 265
(decimal)
N/A N/A
010A HSL loop number 266
(decimal)
N/A N/A
010B HSL loop number 267
(decimal)
N/A N/A
010C HSL loop number 268
(decimal)
N/A N/A
64 iSeries: iSeries Server 270, 800, 810, 820, 825, 830, 840, 870, 890, SB2, and SB3 Hardware Problem Analysis and Isolation
