Table 4. Card position for Models 800, 810 and 825
Model
number
Bus number
in DSA
Multi-adapter
bridge number in
DSA
Multi-adapter
bridge function
number in DSA Item DSA points to
Position label and
PCI data width
800, 810 0001 1 0 Embedded IOP MB1
800, 810 0001 1 1 PCI IOP or IOA card C07 (32 bit)
800, 810 0001 1 2 PCI IOP or IOA card C01 (32 bit)
800, 810 0001 1 3 PCI IOP or IOA card C06 (32 bit)
800, 810 0001 1 4 PCI IOP or IOA card C05 (32 bit)
800, 810 0001 1 5 PCI IOP or IOA card C04 (32 bit)
800, 810 0001 1 6 PCI IOP or IOA card C03 (32 bit)
800, 810 0001 1 7 PCI IOP or IOA card C02 (32 bit)
800, 810 0001 1 F Multi-adapter bridge MB1
800, 810 0001 7 0 Service processor MB1
825 001 2 0 PCI IOP C07
825 001 2 1 PCI IOP C07
825 001 2 2 Embedded Ethernet IOA CB1
825 001 2 3 Unused CB1
825 001 2 4 PCI IOP or IOA card C06
825 001 2 5 PCI IOP or IOA card C06
825 001 2 6 PCI IOP or IOA card C05
825 001 2 7 PCI IOP or IOA card C05
825 001 2 F Multi-adapter bridge CB1
825 001 7 0 Service processor CB1
825 002 2 0 PCI IOP or IOA card C12
825 002 2 1 PCI IOP or IOA card C12
825 002 2 2 PCI IOP or IOA card C11
825 002 2 3 PCI IOP or IOA card C11
825 002 2 4 Unused CB1
825 002 2 5 Unused CB1
825 002 2 6 IOA card C10
825 002 2 7 IOA card C10
825 002 2 F Multi-adapter bridge MB1
825 003 2 0 PCI IOP or IOA card C04
825 003 2 1 PCI IOP or IOA card C04
825 003 2 2 PCI IOP or IOA card C03
825 003 2 3 PCI IOP or IOA card C03
825 003 2 4 PCI IOP or IOA card C02
825 003 2 5 PCI IOP or IOA card C02
825 003 2 6 IOA card C01
825 003 2 7 IOA card C01
825 003 2 F Multi-adapter bridge MB1
66 iSeries: iSeries Server 270, 800, 810, 820, 825, 830, 840, 870, 890, SB2, and SB3 Hardware Problem Analysis and Isolation
