IBM iSeries 820 Hardware Problem Analysis And Isolation

Decimal
loop
number
Hexadecimal
loop number
System
model
NIC’s FRU
position HSL port labels on system unit or processor tower
266 010A Models 870
and 890
M30 ″A0″ and ″A1″ on the NIC card in position M30
267 010B Models 870
and 890
M30 ″B0″ and ″B1″ on the NIC card in position M30
268 010C Models 870
and 890
M39 ″C0″ and ″C1″ on the NIC card in position M39
269 010D Models 870
and 890
M39 ″D0″ and ″D1″ on the NIC card in position M39
For models 830/SB2, see Figure 4. Network Interface Controller (NIC) port locations in the Locations -
Models 830, SB2 page.
For models 840/SB3, see Figure 5. Network Interface Controller (NIC) port locations in the Locations -
Models 840, SB3 page.
Bus-PIP procedures:
Bus-PIPs:
v Bus-PIP 1
v Bus-PIP 2
v Bus-PIP 3
v Bus-PIP 5
v Bus-PIP 6
v Bus-PIP 7
v Bus-PIP 8
v Bus-PIP 9
v Bus-PIP 10
v Bus-PIP 11
Bus-PIPs
for migrated towers
“Bus PIP CNSL01” on page 77
HSL Bus-PIPs:
v Bus-PIP HSL01
v Bus-PIP HSL02
v Bus-PIP HSL03
v Bus-PIP HSL04
v Bus-PIP HSL05
v Bus-PIP HSL06
v Bus-PIP HSL07
v Bus-PIP HSL08
IOP
Bus-PIPs:
v “Bus PIP IOP-01, IOP reset” on page 89
v “Bus PIP IOP-02, Isolate to failing I/O adapter resource” on page 90
74 iSeries: iSeries Server 270, 800, 810, 820, 825, 830, 840, 870, 890, SB2, and SB3 Hardware Problem Analysis and Isolation
