IBM iSeries Series Analyze Hardware Problems (System Reference Codes

contain up to five FRUs. Eight characters of this data represent a single FRU. The
FRU characters have two parts: a unit reference code, and a type number. The
location of this data is shown below:
PANEL FUNC 11: B4xx____ RC01TP01
RC02RC03 RC04RC05
PANEL FUNC 12: DATA0012 DATA0013
TP02TP03 TP04TP05
PANEL FUNC 13: DATA0016 DATA0017
DATA0018 DATA0019
The FRU information for FRU 1 would be RC01 and TP01, for FRU 2 would be
RC02 and TP02, etc.
Characters Description / Meaning Length
RC01 FRU 1 - Ref Code 4 Characters
TP01 FRU 1 - Type 4 Characters
RC02 FRU 2 - Ref Code 4 Characters
TP02 FRU 2 - Type 4 Characters
RC03, TP03, RC04, TP04, RC05, TP05 same as above.
DATA012, DATA013,
DATA016, DATA017,
DATA018, DATA019
Miscellaneous Data - Not applicable, but
may be needed for your next level of
support.
8 Characters
The example below shows relevant data for three FRUs:
RC01=4300, TP01=245C, RC02=8200, TP02=2881, RC03=8600, TP03=2732,
the remaining values are zeroes.
PANEL FUNC 11: B437____ 4300245C
82008600 00000000
PANEL FUNC 12: xxxxxxxx xxxxxxxx
28812732 00000000
PANEL FUNC 13: xxxxxxxx xxxxxxxx
xxxxxxxx xxxxxxxx
Characters Description / Meaning Length
4300 FRU 1 - Ref Code = 4300 4 Characters
245C FRU 1 - Type = 245C 4 Characters
8200 FRU 2 - Ref Code = 8200 4 Characters
2881 FRU 2 - Type = 2881 4 Characters
8600 FRU 3 - Ref Code = 8600 4 Characters
2732 FRU 3 - Type = 2732 4 Characters
Below is the information as shown in a MSD SCREEN:
1 - B4xx____RC01TP01RC02RC03RC04RC05
2 - DATA0012
3 - DATA0013
4- TP02TP03
5- TP04TP05
B437
System Reference Codes 249
