IBM p5 520 - Page 6

4.6
4.7
4.5
From the front, finger-tighten one of the rack-retaining screws in the first hole
above the front alignment pin .
I
J
From the front, attach the system-unit-
latch bracket by inserting the hook
into the rack hole above the hole
where you will place the latch bracket
screw. Finger-tighten the screw.
K
L
K
L
I
J
C
3.
Align the retracted back pins with the holes as identified by the self-adhesive
placement dot. Place the rack flange between the slide-rail flange and the
retracted alignment pins .
Press the back latch-assembly-release tab to extend the back alignment pins into
the back of the rack.
E
FG
E
C
4.
From the back, finger-tighten one of the rack-retaining screws in the hole that
is located between the two back alignment pins .
H
E
4.8
Repeat steps 4.4 through 4.7 for
each slide rail assembly.
Actual size
part 26H7213
Actual size
part 12J5289
F
Actual size
part 12J5289
G
E
H
