6
Install the cable-management arm
B
C
D
E
A
6.3
From the back of the rack, use the pin to affix the cable-management arm to the
left slide-rail management arm flange that is attached to the rack frame .
AE
D-
6.1
Locate the cable-management arm and the two pins .EA
6.2
Use the second pin to affix the other end of the cable-management arm to the
flange that is attached to the sliding portion of the left slide rail assembly .
A
CB
E
Tip: If space is limited inside the rack, slide the server out part of the way to install the
cable-management arm.
