Table 21. FRU location table (continued)
Failing item name Physical location code Identify LED
Failing item
removal and
replacement
procedures
Integrated 10 Gb or 1 Gb ethernet port Un-P2-C8-T3 Yes
Integrated 10 Gb or 1 Gb ethernet port Un-P2-C8-T4 Yes
USB top port (HEA Card) Un -P2-C8-T5 Yes
USB bottom port (HEA Card) Un -P2-C8-T6 Yes
Integrated serial port (HEA Card) Un-P2-C8-T7 Yes
External SAS cable connector Un-P2-T2 Yes
Integrated serial controller Un-P2-T5 Yes
Integrated Serial Advanced Technology
Attachment (SATA) controller
Un-P2-T3 Yes
Integrated SAS controller (A) Un-P2-C9-T1 Yes
Integrated SAS controller (B) Un-P2-C9-T2 Yes
FSP cable connector Un-P2-T1 Yes
IB 0 connector (1) (left) Un-P1-C2-T1 Yes
IB 1 connector (1) (right) Un-P1-C2-T2 Yes
IB 0 connector (2) (left) Un-P1-C3-T1 Yes
IB 1 connector (2) (right) Un-P1-C3-T2 Yes
Processor and processor regulator
Processor card regulator 1 (40P) Un-P3-C21 Yes
Processor voltage regulator module
(VRM)
Un-P3-C23 Yes
Processor card regulator 3 (20P) Un-P3-C24 Yes
Processor VRM Un-P3-C26 Yes
Memory VRM Un-P3-C5 Yes
Processor VRM Un-P3-C14 Yes
Memory VRM Un-P3-C16 Yes
TPMD card Un-P3-C15 Yes
SCM - P7-0 Un -P3-C22
SCM - P7-1 Un -P3-C25
Fabric Bus A- P7 - 0 Bus cable connector Un-P3-T1
Fabric Bus B- P7- 0 Bus cable connector Un-P3-T2
Fabric Bus A- P7 -1 Bus cable connector Un-P3-T3
Fabric Bus B- P7- 1 Bus cable connector Un-P3-T4
Fan connector (leftmost) Un-P3-T5
Fan connector (second from left) Un-P3-T6
Fan connector (third from left) Un-P3-T7
Fan connector (second from right) Un-P3-T8
Fan connector (rightmost) Un-P3-T9
VPD card Un-P2- C7
Finding parts, locations, and addresses 71
