IBM Power 740 Express 8205-E6B

Table 21. FRU location table (continued)
Failing item name Physical location code Identify LED
Failing item
removal and
replacement
procedures
Service processor
FSP cable A connector Un-P1-C1-T1 Yes
FSP cable Drawer 4 connector Un-P1-C1-T1 Yes
FSP cable Drawer 3 connector Un-P1-C1-T2 Yes
FSP cable Drawer 1, 2 connector Un-P1-C1-T3 Yes
FSP cable Drawer 5 connector Un-P1-C1-T4 Yes
FSP USB port Un-P1-C1-T5 Yes
Time-of-day (TOD) Un-P1-C1
Time-of-day Battery Un-P1-C1-E1
HMC 1 connector Un-P1-C1-T6 Yes
HMC 2 connector Un-P1-C1-T7 Yes
SPCN 0 connector Un-P1-C1-T8
SPCN 1 connector Un-P1-C1-T9
Ambient temperature sensor Un-D1
Adapters
PCI-E adapter in slot 1 Un-P2-C1 Yes
PCI-E adapter in slot 2 Un-P2-C2 Yes
PCI-E adapter in slot 3 Un-P2-C3 Yes
PCI-E adapter in slot 4 Un-P2-C4 Yes
PCI-E adapter in slot 5 Un-P2-C5 Yes
PCI-E adapter in slot 6 Un-P2-C6 Yes
1 Gb or10 Gb HEA daughter card Un-P2-C8
FSP card Un-P1-C1 Yes
Expansion card - GX++ (Slot 1) Un-P1-C2 Yes
Expansion card - GX++ (Slot 2) Un-P1-C3 Yes
Disk drive controller Un-P2-C9 Yes
175 MB cache RAID and dual storage
IOA enablement card
Un-P2-C9-C1 Yes
Memory modules
Memory module 1 Un-P3-C1 Yes
Memory module 2 Un-P3-C2 Yes
Memory module 3 Un-P3-C3 Yes
Memory module 4 Un-P3-C4 Yes
Memory module 5 Un-P3-C6 Yes
Memory module 6 Un-P3-C7 Yes
Memory module 7 Un-P3-C8 Yes
Memory module 8 Un-P3-C9 Yes
Memory module 9 Un-P3-C10 Yes
72 Finding parts, locations, and addresses
