Table 4. SAS subsystem storage configurations (continued)
SAS subsystem
configuration
Supported SAS
RAID adapter
External SAS
components SAS port cables SAS cables Limitations
Expanded
function storage
configuration
Two PCIe3 x8 cache
SAS RAID internal
adapters 6 Gb (CCIN
57D8)
Two external SAS 4x
ports that are used for
expansion to external
SAS drawer FC 5887
Yes Internal mini SAS HD
cables
Only one external SAS
drawer FC 5887 is
supported from the
external SAS ports.
Related concepts:
“SAS subsystem service considerations” on page 11
There are several considerations to review before servicing features within the SAS subsystem for the
5148-21L, 5148-22L, 8247-21L, 8247-22L, 8247-42L, 8284-21A, 8284-22A, 8286-41A, or 8286-42A system.
Related information:
Serial-attached SCSI cable planning
Serial-attached SCSI cable planning
SAS subsystem base function storage configuration for the 5148-21L,
8247-21L, 8247-22L, 8247-42L, 8284-21A, 8284-22A, 8286-41A, or
8286-42A
This configuration uses the base function disk drive backplane.
The base function storage configuration includes:
v One PCIe3 x8 SAS RAID internal adapter 6 Gb, with RAID 0,10,5,6
v One base function disk drive backplane that supports 12x SFF (2.5") bays
v One Slimline DVD bay
v Two mini SAS HD cables
Example: Base function disk drive backplane for 5148-21L, 8247-21L, 8247-22L,
8284-21A, or 8284-22A
6 SAS subsystem
