7109 or 5889 PDU+
Table 89. 7109 or 5889 PDU+ features
PDU Number Supported power cords (PDU to wall)
7109 or 5889 PDU+ “Supported PDU power cords” on page 91
Table 90. 7109 PDU+ specications
Characteristics Properties
PDU number 7109
Height 43.9 mm (1.73 in.)
Width 447 mm (17.6 in.)
Depth 350 mm (13.78 in.)
Additional clearance 25 mm (0.98 in.) for circuit breakers
3 mm (0.12 in.) for outlets
Weight (not including power cord) 6.3 kg (13.8 lb)
Weight of power cord (approximate) 5.4 kg (11.8 lb)
Operating temperature at 0 - 914 m (0 -
3000 ft) (room ambient)
10°C - 32°C (50°F - 90°F)
Operating temperature at 914 - 2133 m
(3000 - 7000 ft) (room ambient)
10°C - 35°C (50°F - 95°F)
Operating humidity 8% - 80% (noncondensing)
Localized air temperature in PDU 60°C (140°F) maximum
Rated frequency (all feature codes) 50 - 60 Hz
Circuit breakers Six double-pole branch rated circuit breakers that are rated at
20 A
Power outlet 12 IEC 320-C13 outlets that are rated at 10 A (VDE) or 15 A (UL/
CSA)
7196 PDU+
Table 91. 7196 PDU+ features
PDU Number Supported power cords (PDU to wall)
7196 PDU+ Fixed power cord with IEC 60309, 3P+E, 60 A plug
Table 92. 7196 PDU+ specications
Characteristics Properties
PDU number 7196
Height 43.9 mm (1.73 in.)
Width 447 mm (17.6 in.)
Depth 350 mm (13.78 in.)
100 Power Systems: Site and hardware planning
