Site and hardware planning
Learn about the specications that site planners can use to assess the physical site and operational
requirements necessary to prepare your site for a new server. This information includes specications for
servers and expansion units, plugs and receptacles, and cables, and information about power-distribution
units and uninterruptible power supplies.
Hardware specication sheets
Hardware specication sheets provide detailed information for your hardware, including dimensions,
electrical, power, temperature, environment, and service clearances.
Server specications
Server specications provide detailed information for your server, including dimensions, electrical, power,
temperature, environment, and service clearances.
Select the appropriate models to view the specications for your server.
Model 9008-22L, 9009-22A, 9009-41A, 9009-42A, 9223-22H, and 9223-42H server specications
Server specications provide detailed information for your server, including dimensions, electrical, power,
temperature, environment, and service clearances.
Use the following specications to plan for your server.
Table 2. Dimensions for the 9008-22L, 9009-22A, and 9223-22H
1
Width Depth Height EIA units Weight
482 mm (18.97 in.) 766.5 mm (30.2
in.)
86.7 mm (3.4 in.) 2 30.4 kg (67 lb)
Note:
1. The depth is measured from the front bezel to the back of the top cover. The depth from the front
rack EIA mounting post to the back of the server where the PCI cables exit is 713 mm (28 inches).
Table 3. Dimensions for the 9009-41A, 9009-42A, and 9223-42H
1
Width Depth Height EIA units Weight
482 mm (18.97 in.) 769.6 mm (30.3
in.)
173.3 mm (6.8 in.) 4 36.3 kg (80 lb)
(9009-41A)
39.9 kg (88 lb)
(9009-42A and
9223-42H)
Note:
1. The depth is measured from the front bezel to the back of the top cover. The depth from the front
rack EIA mounting post to the back of the server where the PCI cables exit is 713 mm (28 inches).
Table 4. Shipping dimensions for the 9008-22L, 9009-22A, and 9223-22H (without pallet)
Width Depth Height Weight
991 mm (39 in.) 597 mm (24 in.) 261 mm (10.3 in.) 45 kg (99 lb)
©
Copyright IBM Corp. 2018, 2019 7
