IBM Power System L922 Site And Hardware Planning

Table 5. Shipping dimensions for the 9009-41A, 9009-42A, and 9223-42H (without pallet)
Width Depth Height Weight
610 mm (24.0 in.) 1016 mm (40.0 in.) 345 mm (13.6 in.) 53.7 kg (118.5 lb)
Table 6. Pallet dimensions for the 9008-22L, 9009-22A, 9009-41A, 9009-42A, 9223-22H, and 9223-42H
Width Depth Height Weight
610 mm (24 in.) 1016 mm (40 in.) 125 mm (5 in.) 10 kg (22 lb)
Table 7. Electrical characteristics for the 9008-22L, 9009-22A, 9009-41A, 9009-42A, 9223-22H, and
9223-42H
Electrical characteristics Properties
AC rated voltage and frequency
2
900 W PSU: 100 - 127 V ac or 200 - 240 V ac at 50 or
60 Hz plus or minus 3 Hz (9009-41A)
1400 W PSU: 200 - 240 V ac at 50 or 60 Hz plus or
minus 3 Hz (9008-22L, 9009-22A, 9223-22H,
9009-42A, and 9223-42H)
Thermal output (maximum)
3
6416 BTU/hr (9008-22L, 9009-22A, and 9223-22H)
5461 BTU/hr (9009-41A)
9386 BTU/hr (9009-42A and 9223-42H)
Maximum power consumption
3
1880 W (9008-22L, 9009-22A, and 9223-22H)
1600 W (9009-41A)
2750 W (9009-42A and 9223-42H)
Maximum kVA
4
1.94 kVA (9008-22L, 9009-22A, and 9223-22H)
1.65 kVA (9009-41A)
2.835 kVA (9009-42A and 9223-42H)
Phase Single
Notes:
1. Redundancy is supported. The 9008-22L, 9009-22A, and 9223-22H have a maximum of two power
supplies, but can operate on one power supply. The 9009-41A, 9009-42A, and 9223-42H have a maximum
of four power supplies, but can operate on two power supplies.
2. The power supplies automatically accept any voltage with the published, rated-voltage range. If multiple
power supplies are installed and operating, the power supplies draw approximately equal current from the
utility (electrical supply) and provide approximately equal current to the load.
3. Power draw and heat load vary greatly by conguration. When you plan for an electrical system, it is
important to use the maximum values. However, when you plan for heat load, you can use the IBM Systems
Energy Estimator to obtain a heat output estimate based on a specic conguration. For more information,
see The IBM Systems Energy Estimator website.
4. To calculate the amperage, multiply the kVA by 1000 and divide that number by the operating voltage.
Table 8. Environment requirements
Environment requirements
Environment (operating)
1
8 Power Systems: Site and hardware planning
