Table 2. Parts of the FC EU04 and EUA4 External Docks (continued)
FRU Part number Description
01GY552 or 01GY553 External power supply with power cord and universal plugs for all supported
geographies (FC EUA4)
05H5081 or 05H5080 External USB 3.0 Cable (2.7 meters (8 ft 10 in))
39M5516 Power cord (1 meter (3.28 ft)) that connects the power supply to the rack power
distribution unit
The supported disk drives in the FC EU04 and EUA4 are listed in the following table:
Table 3. Removable disk drives
Feature code Part number Description
EU08 46C5377 320 GB Removable Disk Drive (FC EU04)
1107 46C5379 500 GB Removable Disk Drive (FC EU04 and EUA4)
EU01 46C2335 1 TB Removable Disk Drive (FC EU04 and EUA4)
EU15 46C2831 1.5 TB Removable Disk Drive (FC EU04)
EU2T 46C2975 2 TB Removable Disk Drive (FC EU04 and FC EUA4)
Purchasing extra removable disk drives
For best results, use only the removable disk drives that are listed in Table 3.
The removable disk drives are a supply item that can be ordered as a feature code. To order in the United
States and Canada, call 1-888-IBM-MEDIA. To order drives in other locations, contact your local provider
of IBM storage products or see the Storage Media (http://www-03.ibm.com/systems/storage/media/)
website.
IBM service representatives will not be dispatched to service or replace the removable disk drives.
Storing removable disk drives
Store removable disk drives in their protective containers, on a flat surface with the top side up. The
storage area must be clean and dry, must have normal room temperature, and must be away from any
magnetic fields. For best storage life, use the removable disk drives every six months.
Supported USB adapters and cables
Attention: The docking station supports the USB cable that is provided as part of the feature code. The
docking station does not support attachment by using other USB cables, USB hubs, add-on USB cables, or
USB cable extenders.
The external docking station can be connected to the external, integrated USB ports on POWER8
®
processor-based systems or can be connected to the USB ports on the PCIe2 LP 4-Port USB 3.0 Adapter
(FC EC45) or PCIe2 4-Port USB 3.0 Adapter (FC EC46).
Specifications
Interface
USB 3.0
Mksysb
Yes
4 Managing devices
