IBM System x3850 X5 15
Table 9. Memory options - MAX5 V2, 88Y6529
Part number MAX5 V2
feature code
Description
44T1592 2429 2GB MAX5 1x2GB 1Rx8 1.5V PC3-10600 CL9 ECC DDR3 1333MHz LP RDIMM
49Y1407 A1MH 4GB MAX5 (1x4GB, 2Gb, 2Rx8, 1.35V) PC3L-10600R-999 LP ECC RDIMM
44T1599 2431 4GB MAX5 1x4GB DualRankx8 PC310600 CL9 ECC DDR3 1333MHz LP RDIMM
46C7482 2432 8GB MAX5 1x8GB QuadRankx8 PC3-8500 CL7 ECC DDR3 1066MHz LP RDIMM
49Y1399 A1N7 8GB MAX5 1x8GB, 4Rx8, 1.35V PC3L-8500 CL7 ECC DDR3 1066MHz LP
RDIMM
46C7483 2433 16GB MAX5 1x16G QuadRankx4 PC3-8500 CL7 ECC DDR3 1066MHz LP
RDIMM
None A3E1 16GB MAX5 1x16GB 2Rx4 1.35V PC3L-10600 CL9 ECC DDR3 1333MHz LP
RDIMM
49Y1400 A1N8 16GB MAX5 1x16GB 4Rx4 1.35V PC3L-8500 CL7 ECC DDR3 1066MHz LP
RDIMM
90Y3101 A1R2 32GB MAX5 (4GB, 4Rx4, 1.35V) PC3L-8500 DDR3-1066MHz LP RDIMM
Table 10. Memory options - MAX5, 59Y6265
Part number MAX5
feature code
Description
44T1592 2429 2GB MAX5 1x2GB 1Rx8 1.5V PC3-10600 CL9 ECC DDR3 1333MHz LP RDIMM
44T1599 2431 4GB MAX5 1x4GB DualRankx8 PC310600 CL9 ECC DDR3 1333MHz LP RDIMM
46C7482 2432 8GB MAX5 1x8GB QuadRankx8 PC3-8500 CL7 ECC DDR3 1066MHz LP RDIMM
46C7483 2433 16GB MAX5 1x16G QuadRankx4 PC3-8500 CL7 ECC DDR3 1066MHz LP
RDIMM
The following memory protection technologies are supported:
ECC

ChipKill

Memory Mirroring

Memory Sparing

Redundant Bit Steering (MAX5, or servers with E7 processors only, x4 DIMMs only)


IBM Redbooks x3850 X5 Specifications

General

Network Interface	Integrated dual-port Gigabit Ethernet
Storage	Up to 16 x 2.5-inch SAS/SATA HDDs or SSDs
Form Factor	4U rack
Chipset	Intel 7500
RAID Support	RAID 0, 1, 5, 6, 10
Operating System Support	Microsoft Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware ESXi
Storage Controller	ServeRAID M5015 or M5025
