IBM System x3850 X5 8
Table 1. Standard specifications (Part 2)
Components Specification
Limited warranty Three-year customer-replaceable unit and onsite limited warranty.
Dimensions Width: 440 mm (17.3 inches), depth: 712 mm (28.0 inches), height: 173 mm (6.8
inches) or 4 rack units (4U)
Weight Minimum configuration: 35.4 kg (78 lb), maximum configuration: 49.9 kg (110 lb)
The x3850 X5 servers are shipped with the following items:
Rack rails and hardware

Cable management hardware

Country kit carton

Two 2.8 m 220 V intra-rack cables

On/off switch cover

Documentation CD

Standard models
The following table lists the standard models.
Table 2. Standard models - Machine type 7143 (Intel Xeon E7-4800 and E7-8800 series processors)
Model
7143-
Intel Xeon CPUs (4 max) (quantity,
model, core speed, cores, L3 cache,
memory speed)
Scale
without
MAX5‡
Scale
with
MAX5‡
MAX5 Memory
(cards)*
RAID Bays
(std/max)
(No disks)
10G
Std
Std
PS
B1x 2x E7-4807 6C 1.86GHz 18MB 800 No Yes Opt 2x4GB (1) Opt 0 / 8 (2.5") Opt 1
B2x 2x E7-4820 8C 2.00GHz 18MB 1066 No Yes Opt 4x4GB (2) M1015 4 / 8 (2.5") Std 2
B3x 2x E7-4830 8C 2.13GHz 24MB 1066 No Yes Opt 4x4GB (2) M1015 4 / 8 (2.5") Std 2
B5x 2x E7-4850 10C 2.00GHz 24MB 1066 No Yes Opt 4x4GB (2) M1015 4 / 8 (2.5") Std 2
B6x 2x E7-4860 10C 2.26GHz 24MB 1066 No Yes Opt 4x4GB (2) M1015 4 / 8 (2.5") Std 2
B7x 2x E7-4870 10C 2.40GHz 30MB 1066 No Yes Opt 4x4GB (2) M1015 4 / 8 (2.5") Std 2
C1x 2x E7-8850 10C 2.00GHz 24MB 1066 Yes Yes Opt 4x4GB (2) M1015 4 / 8 (2.5") Std 2
C2x 2x E7-8860 10C 2.26GHz 24MB 1066 Yes Yes Opt 4x4GB (2) M1015 4 / 8 (2.5") Std 2
C3x 2x E7-8870 10C 2.40GHz 30MB 1066 Yes Yes Opt 4x4GB (2) M1015 4 / 8 (2.5") Std 2
‡ Columns indicate whether the server can scale to two nodes without a MAX5 attached and with a MAX5 attached.
* The number in brackets is the number of memory cards standard in each model. Up to eight cards are supported.
Each holds up to eight DIMMs for a total of 64 DIMMs. The MAX5 adds 32 DIMM sockets for a total of 96 DIMMs.

IBM Redbooks x3850 X5 Specifications

General

Network Interface	Integrated dual-port Gigabit Ethernet
Storage	Up to 16 x 2.5-inch SAS/SATA HDDs or SSDs
Form Factor	4U rack
Chipset	Intel 7500
RAID Support	RAID 0, 1, 5, 6, 10
Operating System Support	Microsoft Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware ESXi
Storage Controller	ServeRAID M5015 or M5025
