IBM System x3850 X5 18
Table 12. Disk drive options for internal disk storage (Part 3)
Part number Feature
code
Description Maximum
supported
2.5-inch solid state drives (SSDs) - Enterprise Value
00AJ000 A4KM S3500 120GB SATA 2.5" MLC HS Enterprise Value SSD 8
00AJ005 A4KN S3500 240GB SATA 2.5" MLC HS Enterprise Value SSD 8
00AJ010 A4KP S3500 480GB SATA 2.5" MLC HS Enterprise Value SSD 8
00AJ015 A4KQ S3500 800GB SATA 2.5" MLC HS Enterprise Value SSD 8
49Y5844 A3AU IBM 512GB SATA 2.5" MLC HS Enterprise Value SSD 8
90Y8643 A2U3 IBM 256GB SATA 2.5" MLC HS Enterprise Value SSD 8
90Y8648 A2U4 IBM 128GB SATA 2.5" MLC HS Enterprise Value SSD 8
49Y5839 A3AS IBM 64GB SATA 2.5" MLC HS Enterprise Value SSD 8
2.5-inch SAS-SSD hybrid drives
00AD102 A4G7 IBM 600GB 10K 6Gbps SAS 2.5'' G2HS Hybrid 8
2.5-inch NL SAS hot-swap HDDs
81Y9690 A1P3 IBM 1TB 7.2K 6Gbps NL SAS 2.5" SFF HS HDD 8
42D0707 5409 IBM 500GB 7200 6Gbps NL SAS 2.5" SFF Slim-HS HDD 8
81Y9726 A1NZ IBM 500GB 7.2K 6Gbps NL SATA 2.5" SFF HS HDD 8
90Y8953 A2XE IBM 500GB 7.2K 6Gbps NL SAS 2.5" SFF G2HS HDD 8
2.5-inch NL SATA hot-swap HDDs
81Y9730 A1AV IBM 1TB 7.2K 6Gbps NL SATA 2.5" SFF HS HDD 8
42D0752 5407 IBM 500GB 7200 NL SATA 2.5" SFF Slim-HS HDD 8
81Y9722 A1NX IBM 250GB 7.2K 6Gbps NL SATA 2.5" SFF HS HDD 8

IBM Redbooks x3850 X5 Specifications

General

Network Interface	Integrated dual-port Gigabit Ethernet
Storage	Up to 16 x 2.5-inch SAS/SATA HDDs or SSDs
Form Factor	4U rack
Chipset	Intel 7500
RAID Support	RAID 0, 1, 5, 6, 10
Operating System Support	Microsoft Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware ESXi
Storage Controller	ServeRAID M5015 or M5025
