Index
Number
Part Number Units
Per
Asm
Description
1 89X2627 1 Caster, (offset) left
2 89X2628 1 Caster, (offset) right
3 1621823 16 Screw, hex Hd w/washer, self tap, M6 x 16
4 1622306 16 Washer
5 1622320 16 Lock washer
6 1621596 16 Screw
7 62X3601 2 Caster, Swivel
8 93H8181 1 Stabilizer
9 93H9182 2 Thumbscrews
10 93H7817 1 Front Door
11 93H8220 1 Rear Door
12 11F0118 2 Hinge pin, rear door
13 1621098 2 Screws
14 93H7378 1 Ground Strap
15 1622348 2 Star Washers
16 93H7372 2 Pins
17 93H7374 2 Bearings
18 27760 2 Washers
19 07L7168 1 Door Ramp Mounting Screw, M3 x 10
Chapter 6. Parts Information 6-3
