Index
Number
Part Number Units
Per
Asm
Description
1 02G7232 1 Rail, left (for CPU Enclosures)
1 375816 1 Rail, left (for non-CPU Enclosures)
2 02G7263 1 Rail, right (for CPU Enclosures)
2 375714 1 Rail, right (for non-CPU Enclosures)
3 97H9754 1 Front bezel (for empty drawer position), 1 EIA unit
4 97H9755 1 Front bezel (for empty drawer position), 3 EIA units
5 97H9756 1 Front bezel (for empty drawer position), 5 EIA units
6 0375867 4 Nut clip
7 02G7295 4 Screw, rail mounting
8 1624779 2 Screw, M5 x 14
9 1622319 2 Lock washer
10 1622404 2 Nut
11 1622320 4 Lock washer
12 1622405 4 Nut
13 1621210 2 Screw, pan head, M5 x 10
Chapter 6. Parts Information 6-7
