IBM RS/6000 7014-S00

Circuit Breaker Panel (Front View)
Circuit Breaker
Switches
(Bank A)
Circuit Breaker
Switches
(Bank B)
A
A
BB
Circuit Breaker Panel (Rear View)
Device
Connections
(Bank B)
Device
Connections
(Bank A)
-48 V DC Input
(Bank B)
-48 V DC Input
(Bank A)
Positive Ground
(Bank B)
Positive Ground
(Bank A)
Ground Cable
Connector
Ground Cable
Connector
(not pictured)
1-14 7014 Model S00 Rack Installation and Service Guide
