Step 7. Connect Drawer and Device Cables
1. If head protectors are installed, remove them from all diskette drives.
2. Most systems in Model S00 racks are preconfigured in the factory, with all
drawer and device cables installed. If you need to install drawer and device
cables:
a. Follow the power control cable installation instructions provided in the
documentation for the appropriate system or device being installed in this
rack.
b. Using the customer planning information, the
Diagnostics Information for
Multiple Bus Systems
, or other information supplied by the customer, connect
the drawer and device cables to the system interface board ports.
c. As needed, use the cable labels included in the ship group to label the
cables. For additional information about labeling the cables, refer to the
Diagnostics Information for Multiple Bus Systems
.
3. Cable restraints are supplied with the rack and can be installed in the rack.
a. Open the cable restraint strap by pressing the release tab and then pulling
the end of the cable restraint strap through the locking mechanism.
b. Place the cables within the cable restraint strap.
c. Close the strap by placing the end of the cable restraint strap through the
locking mechanism, and then pull the end of the cable restraint strap to
tighten the cables against the rack.
Step 8. Power-On and Check Out the System
1. Follow the power-on procedures in Chapter 4, Removal and Replacement for the
power distribution systems installed in your rack.
2. Refer to the
Diagnostics Information for Multiple Bus Systems
and follow the
instructions in the installation checkout procedure.
Chapter 2. System Installation 2-35
