SP Checkpoints
Service Processor checkpoints are in the range E010 to E0FF. The message OK
indicates successful service processor testing and initialization. Firmware checkpoints
are listed in “Firmware Checkpoints” on page 3-32.
Note: Go to MAP 1540 for any of the following conditions:
A four-digit code in the range of E001 through EFFF displays on the operator
panal but is not listed in the checkpoint table.
A four-digit code displays in the checkpoint table, but does not contain a repair
action or FRU listing.
All of the FRUs listed in the repair action have been replaced and the problem
has not been corrected.
Table 3-4 (Page 1 of 3). SP Checkpoints.
Checkpoint Description Action/
Possible Failing FRU
E000 System Support Controller begins
operation. This is an informational
checkpoint.
See the note on 3-30.
E010 Starting SP self-tests 1. Service Processor.
2. I/O board. (See notes on 3-1.)
E011 SP self-tests completed successfully NA
E012 Begin to set up SP heaps Service Processor.
E020 Configuring CMOS 1. I/O board. (See notes on 3-1.)
2. Service Processor.
E021 Configuring NVRAM 1. I/O board. (See notes on 3-1.)
2. Service Processor.
E030 Beginning to build I2C resources 1. Service Processor.
2. CPU Card.
3. I/O board. (See notes on 3-1.)
E031 Finished building I2C resources 1. Service Processor.
2. CPU Card.
3. I/O board. (See notes on 3-1.)
E040 Starting serial port tests 1. Service Processor.
2. I/O board. (See notes on 3-1.)
3. CPU Card.
3-30 RS/6000 Enterprise Server Model H50 Installation and Service Guide
To Next Page
