Index Part Number Units Per Description
3 93H8548 1 Inner Cover, back
4 93H2641 1 or 2 Memory Card
93H4700 Up to 8 pair 32MB memory module
93H4702 Up to 8 pair 128MB memory module
5 93H9018 1 or 2 CPU card (1 way)
93H8945 1 or 2 CPU card (2 way)
6 93H4214 1 Service processor
7 93H8570 2 Fan, CPU
81F7977 4 Isolator, CPU Fan
8 07L6594 1 I/O Planar
9 73H1925 1 System Board
10 05L0111 1 Cable guard
11 93H8958 1-2 Power Supply
12 93H8868 1-2 Fan Assembly, power supply
13 93H8819 1 Chassis
14 93H9159 1 Rail, right side
15 93H2166 1-2 SCSI Backplane (Hot swap)
93H6321 0-2 SSA Backplane (Hot swap)
16 93H8840 1 DASD cage
17 93H8807 1 DASD Banks Cover
18 See note Up to 12 Disk drive carrier assembly, SCSI
See note Up to 12 Disk drive carrier assembly, SSA
19 See note Up to 12 Disk drive, SCSI
See note Up to 12 Disk drive, SSA
20 06H2792 1 Plate assembly
21 See note 0-1 Tape drive
22 See note 1 CD-ROM drive
23 93H8806 1 Media Bank Cover
24 93H8837 1 Media cage
25 93H8810 0-1 SCSI Boot Disk Drive
26 93H2922 1 Operator panel control assembly
27 93H9156 1 Rail, left side
28 93H8863 2 Blower
29 93H9551 1 Power Distribution Board
See Note 1 Diskette drive
30 93H8831 1 Air Baffle, bottom
Chapter 8. Parts Information 8-3
