a. Either move the PC and Operations Console port both to the network or re-congure the PC IP
settings to be in the same subnet that you just congured for the service tools LAN adapter.
b. Return to the ACS interface and select the window labeled System Congurations.
c. Click New.
d. If you will use this connection to connect to other functions, type the system name that you plan to
use in the General tab.
e. Click the Console tab.
f. Under the LAN Console/Virtual Control panel, type the IP address of the service tools LAN adapter
in the Service Host Name eld.
g. Click OK.
h. In the main ACS menu, click System and select the system that you created.
i. Under Console, click 5250 Console. Continue with your IPL.
Note: The IP conguration of the PC must be reset before cabling the PC back to the network because the
PC is congured with the gateway IP address. The PC and server console port (T1) can now be re-cabled
to the network.
Continue with “Completing the server setup” on page 19.
Cabling the server with keyboard, video, and mouse
Before you start the system, you might need to connect the keyboard, video, and mouse to the system, if
a graphics card is present.
About this task
To connect the keyboard, video, and mouse, complete the following steps:
Procedure
1. Locate the graphics card and Universal Serial Bus (USB) ports at the rear of the system. You might
need a connector converter.
2. Connect the monitor cable to the graphics card.
3. Connect a keyboard and mouse to the blue USB 3.0 ports.
4. Power on the console.
5. Continue with “Cabling the server and connecting expansion units” on page 18
.
Cabling the server and connecting expansion units
Learn how to cable the server and to connect expansion units.
About this task
To cable the server and to connect expansion units, complete the following steps:
Procedure
1. If a plug is covering a port that you need to use on the rear of the system, remove and discard it. The
port covers ensure that you are reminded that you must reset the Administrator password on your
managed system upon initial system IPL.
2. Complete the following steps:
a. Plug the power cord into the power supply.
Note: If present, remove and discard any plug that covers the ports on the rear of the system. The
port covers ensure that you are reminded about resetting the Administrator password of your
managed system after the initial program load (IPL) completes.
b. Plug the system power cords and the power cords for any other attached devices into the power
source.
18
Power Systems: Installing the IBM Power System S922 (9009-22A and 9009-22G), IBM Power System
H922 (9223-22H), or IBM Power System H922S (9223-22S)
