ServeRAID-6M
128 MB cache: part 32P0033, 2003 and 39R8815, 2006
256 MB cache: part 02R0988, 2003 and 39R8816, 2006
US Announcement Letter: 103-206
Two external connectors and two internal connectors
Adaptec name and logo printed on the board (not IBM)
Two notches in the PCI connector, not three - indicating that it is a 3.3V adapter, not a combo 3.3V+5V adapter
One DIMM attached to the bottom edge of the card (see photo) for the cache
The 128 MB DIMM has five chips (as shown in the photo); the 256 DIMM has nine chips
Note
: The battery shown in the photo is not a production-level battery.
ServeRAID-6i
(part 71P8595, 2003) and
ServeRAID-6i+
(part 13N2190, 2004 and 39R8793, 2006)
US Announcement Letters:
