IBM T00 - Page 45

11. Remove the four mounting screws that attach the dc power distribution panel to the top of the rack,
and remove the panel.
5
4
3
2
1
1 Ground Wire with Connector 4 Ground Wire Connector
2 Mounting Screw (quantity 4) 5 Mounting Screw (This screw secures
both the Power Distribution Panel and
the Ground Wire.)
3 Power Distribution Panel
Chapter 3. Removal and Replacement 33
