IBM T00 - Model T42 Top Frame

Model T42 Top Frame
Index Number FRU Part Number Units Per Assembly Description
1 **21L4296 1 Top Frame
** This is the only orderable top frame FRU number. This part has a default color of white. If you need to have a
black top frame, you will need to request it when placing the order along with the 21L4296 FRU part number.
1a 21L4277 1 Top Cable Access Cover
(Black)
1a 21L4290 1 Top Cable Access Cover
(White)
2 31L7536 2 Top Frame Side Panel
(Black)
2 05N6805 2 Top Frame Side Panel
(White)
3 05N6478 2 Lower Side Panel (Black)
3 05N6477 2 Lower Side Panel (White)
4 11P0313 1 Rack Frame (Black)
4 11P0314 1 Rack Frame (White)
44 7014 Model T00, and Model T42 Service Guide
