10. If necessary, replace the cable channel cover.
1
2
6
5
4
3
1 Mounting Screw (quantity 4) 4 Shield
2 Cable Channel Cover 5 Power Distribution Panel (PDP)
3 Mounting Screw (quantity 6) 6 Front of Rack
11. Have the customer turn on the -48 V dc power source.
12. Follow the steps in “Power-On Procedure with the DC Power Distribution Panel” on page 27.
Chapter 3. Removal and Replacement 35
