No. Description FRU No. Q'ty
8 Internal diskette drive module
(with bracket, bezel, FPC cable
and information label)
11J8570 1
Internal CD-ROM drive module
(with bracket, bezel, FPC cable
and information label)
05K8826 1
9 Diskette drive bezel 12J0524 1
CD-ROM drive bezel 05K4607 1
10 See Miscellaneous/ Mylar pack
11 Fan 05K4605 1
12 Audio connector board (with
Mylar)
11J8584 1
13 Audio connector board FPC
cable
11J8585
14 Chassis (with speaker, LCD
cover switch, PCMCIA door and
Mylar)
05K4655 1
15 Battery pack (NiMH) (with
information label)
11J8604 1
16 Backup battery 11J8591 1
17 System board (without charger,
CPU, PCMCIA socket and
Mylar)
05K3143 1
18 Charger board (with Mylar) 11J8582 1
19 Hard disk drive module
connector board
11J8583 1
20 I/O door 12J0529 1
21 Lower base (with I/O door and
robber foot, without information
label, TrackPoint board and
TrackPoint buttons)
11J8564 1
22 Battery pack door 12J0530 1
23 DIMM door (with screw) 12J0532 1
24 Hard disk drive door 12J0531 1
25 Hard disk drive module lower
cover plate (for 12.7 mm high
hard drive 11J8625 use)
12J0512 1
Hard disk drive module lower
cover plate (for 9.5 mm high
hard drive 05K8825 use)
05K4606 1
26 1.6GB hard disk drive module
assembly
05K8825 1
2.1GB hard disk drive module
assembly
11J8625 1
27 Hard disk drive module upper
cover plate (with information
label and inside Mylar)
11J8568 1
80 IBM Mobile Systems ThinkPad 310 (D/E/ED) HMM
