System (Rear View)
▌1▐ Latches
▌2▐ System Expansion Connector
▌3▐ Docking Door
A MultiPort II or Dock II can be connected to this
interface to support the following features:
16-bit AT-bus interface
Serial port
Parallel port
Keyboard and mouse
Hard disk drive connection
LED control signals
Video signals
Audio signals
Diskette drive
PCMCIA
Power controls
Power line
3
2
1
ThinkPad 701C/701CS (2630) 183
