Notes:
1. When handling the PCMCIA slot assembly, be
careful not to disassemble any part of it. The slot
assembly is not solidly fixed when it is removed from
the system board or the FRU.
2. The screw stand-off located each corner of the
PCMCIA slot, is easy to remove. Make sure that the
screw stand-off is positioned when replacing the slot.
Do not replace the slot without the screw stand.
Use the following table for reference when replacing parts.
Step Location (Quantity) Length
▌1▐ PCMCIA slot, upper (2) 12 mm
▌2▐ PCMCIA slot, lower (2) 14 mm
Note: Make sure you use the correct screw.
260 IBM Mobile Systems HMM
