(Rear View)
Note: When replacing the indicator, insert the flexible
cable straight into the connector until the head of the cable
stops. Slide both ends of the latches at the same time to
make sure that the cable is correctly inserted.
2
2
1
Use the following table for reference when replacing parts.
Step Location (Quantity) Length
▌1▐ Indicator bracket (2) 4 mm
Note: Make sure you use the correct screw.
ThinkPad 355x, 360x, 370C, 750x, 755C, 755Cs 273
