1150 Interposer Card and Rear IR
Battery Pack (1020)
Diskette Drive (1030)
Hard Disk Drive (1040)
Keyboard Unit (1080)
Status Indicator (1090)
Standby Battery and Front IR (1100)
Backup Battery (1110)
Logic Assembly (1115)
Shield Assembly (1120)
DC-DC Card (1130)
DSP Card (1140)
Where:
▌A▐ is the Rear IR.
▌B▐ is the Interposer Card.
Use the following table for reference when replacing parts.
Step Location (Quantity) Length
▌1▐ Interposer card (1) 4 mm
Note: Make sure you use the correct screw.
ThinkPad 755CE, 755CSE, 755CV, 755CX (9545) 447
