IBM ThinkPad 600 Hardware Maintenance Manual

Model-Unique Functions
Model-Unique Functions
Product Overview
The following table is an overview of the system features
of the ThinkPad 600 series:
Feature Description
Processor For 600:
 Intel Pentium MMX 233 MHz,
L2 cache
 Intel Pentium II 233 MHz, L2
cache
 Intel Pentium II 266 MHz, L2
cache
 Intel Pentium II 300 MHz, L2
cache
For 600E:
 Intel Pentium II 300 MHz, L2
cache with AGP
 Intel Mobile Pentium II 300PE
MHz, L2 cache with AGP
 Intel Mobile Pentium II 366 MHz,
L2 cache with AGP
 Intel Mobile Pentium II 400 MHz,
L2 cache with AGP
Bus Architecture For 600:
 PCI Bus
For 600E:
 PCI Bus, AGP Bus
Memory
(Standard)
For 600:
 32 MB (on the system board)
 32 MB (on the system board) and
32 MB in the DIMM slot
For 600E:
 32 MB (on the system board)
 32 MB (on the system board) and
32 MB in the DIMM slot
Memory (Option) For 600:
 16 MB, 32 MB, 64 MB, or 128 MB
DIMM card (maximum of 288 MB)
For 600E:
 32 MB, 64 MB, or 128 MB DIMM
card (maximum of 288 MB)
CMOS RAM 114 bytes +4 Kbytes
ThinkPad 600 49

IBM ThinkPad 600 Specifications

General

Processor	Intel Pentium II
Graphics	Neomagic MagicGraph128XD
Operating System	Windows 95, Windows 98, or Windows NT 4.0
Resolution	800 x 600
Battery	Lithium-Ion
Optical Drive	Optional external CD-ROM drive
Ports	Serial, Parallel, VGA
Network	10/100 Ethernet
Clock Speed	233 MHz to 300 MHz
Display	12.1-inch TFT
