Product Overview
The following table shows an overview of the system
features.
Feature Description
Processor Intel 486DX4 100/33 MHz
Bus Architecture  AT Bus
 VESA Local Bus for video
subsystem
Memory
(Standard)
8MB (on the system board)
Memory (Option)  2, 4, 8, 16MB, Basic IC DRAM
card (max. 16 MB)
 4, 8, 16MB, DIMM card (max. 40
MB)
 DIMM card adapter
CMOS RAM 128 Bytes
VGA Video 10.4-inch, 64K color, TFT LCD color
Diskette Drive
(Removable)
 0.720, 1.2, 1.44, 2.88MB
(4-mode), 3.5-inch
 0.720, 1.44, (2-mode), 3.5-inch
Hard Disk Drive
(Removable)
 340MB, 2.5-inch
 540MB, 2.5-inch
 810MB, 2.5-inch
Super Video
Card
 Video accelerator
 Video capture/overlay
 Video composite In/Out
CD-ROM  5-inch
 Double speed
 IDE interface
DSP Card  Microphone jack
 Headphone jack
 Modem port
IR Two infra-red ports
PCMCIA One Type-III or two Type-II
ThinkPad 755CD, 755CDV (9545) 349
