2120 Shield Assembly
CD-ROM Drive (2030)
Battery Pack (2020)
Hard Disk Drive (2040)
Keyboard Unit (2080)
Status Indicator (2090)
Standby Battery and Front IR (2100)
Backup Battery (2110)
Logic Assembly (2115)
Step Location (Quantity) Length
▌1▐ Shield assembly (3) 4 mm
▌2▐ Shield assembly (3) 14 mm
▌3▐ Shield assembly (1) 8 mm
Note: Make sure you use the correct screw.
ThinkPad 755CD, 755CDV (9545) 367
