1190 Hard-disk drive slot
For access, remove these FRUs, in order:
v “1010 Battery pack” on page 64
v “1050 Mini PCI adapter” on page 70
v “1060 Keyboard” on page 73
v “1070 Backup battery” on page 81
v “1090 PC Card slot assembly” on page 85
v “1100 Hinge cover” on page 87
v “1150 LCD assembly” on page 98
v “1160 Keyboard bezel” on page 103
v “1170 Speaker assembly and microphone cable” on
page 108
v “1180 System board” on page 109
1
2
3
Step Screw (quantity) Torque
1 M2 × 13 mm, Silver (2) 0.294 Nm
(3
kgfcm)
When installing: Make sure that the connector 2 is
firmly attached, and then secure the
screws.
Removing and replacing a FRU
116 ThinkPad R40
