IBM ThinkPad R40 2681 - 1150 LCD assembly

1120 Fan assembly
For access, remove these FRUs, in order:
v “1010 Battery pack” on page 64
v “1060 Keyboard” on page 73
v “1100 Hinge cover” on page 87
4
5
3
2
1
Step Screw (quantity) Torque
1 M2 × 13 mm, Silver (4) 0.294 Nm
(3
kgfcm)
When installing: Make sure that the connector 2 is
firmly attached.
Removing and replacing a FRU
94 ThinkPad R40
