3020 ThinkPad Dock top cover
Note
This section is only for the ThinkPad Dock (FRU no.
08N1546.) Top cover and screw kit for ThinkPad
Dock (FRU part no. 12P4143) is not available for
the ThinkPad Dock with extension plate (FRU part
no. 08N1537.)
1
(Rear view)
Step Screw (quantity) Torque
1 M2.5 × 4.8 mm (2) 39.2 Ncm
(4 kgfcm)
(continued)
Removing and replacing a FRU
ThinkPad T20, T21, T22 and T23 series 135
