Table 88. Rack assembly part numbers (continued)
Index
number
CCIN Part number Units per
assembly
Description
35 2BFB 46K7505 1 System backplane (contains 2 processor modules)
36 5 Attaching screw for system backplane
37 46K5409 1 Heat sink
38 537D 74Y6149 1-2 4 core 3.0 GHz processor module
38 539E 74Y6155 1-2 4 core 3.72 GHz processor module
38 539E 74Y6153 1-2 6 core 3.72 GHz processor module
38 539F 74Y6154 1-2 8 core 3.55 GHz processor module
39 2D1F 74Y2021 1 Interposer card assembly (with RAID feature)
39 2D1E 74Y2022 1 Interposer card assembly
40 74Y7205 1 Interlock switch
41 74Y5197 1 Front Bezel (IBM Power
®
710 Express)
74Y5198 1 Front Bezel (IBM Power 730 Express)
74Y5199 1 Front Bezel (OEM)
Table 89. Cables
Feature code Description Part number
3124 3.7-meter cable 88G4771
3125 8-meter cable 88G4772
3652 1-meter SAS EE cable 44V4147
3653 3-meter SAS EE cable 44V4148
3654 6-meter SAS EE cable 44V4149
3661 3-meter SAS X cable 44V4154
3662 6-meter SAS X cable 44V4155
3663 15-meter SAS X cable 44V4156
3684 3-meter SAS AE cable 44V4163
3685 6-meter SAS AE cable 44V4164
3686 1.5-meter SAS YI cable 44V4161
3687 3-meter SAS Y0 cable 44V4162
3691 1.5-meter SAS Y0 cable 44V4157
3692 3-meter SAS Y0 cable 44V4158
3693 6-meter SAS Y0 cable 44V4159
3694 15-meter SAS Y0 cable 44V4160
USB internal cable for tape drive 46K7435
Internal power cable for tape drive 46K7434
SAS power and logic cable for tape drive 74Y6761
Table 90. Miscellaneous parts
CCIN Description Part number
External cables and cords See Site and hardware
planning.
