Page #3 background image
IBM Asia Pacific Hardware Announcement AG11-0009 IBM is a registered trademark of International Business Machines Corporation
3
1
DDR3 1333 RDIMM memory. DDR3 memory stands for double data rate, which
means up to twice the data is transferred compared to SDRAM in the same clock
cycle.
2
When referring to HDD or tape backup capacity, GB stands for 1,000,000,000 bytes
and TB stands for 1,000,000,000,000 bytes. User capacity may vary depending on
operating environments.
3
Some programs may not be available in all countries.
4
With respect to on-site service, you may be asked certain diagnostic questions
before a technician is sent.
5
For information on the IBM Statement of Limited Warranty, contact your IBM
representative or reseller. Copies are available upon request.
6
Sixteen DIMM slots that enable you to deploy up to 192 GB of DDR3 SDRAM
Registered DIMM memory, with 12 slots populated with 16 GB DIMMs optional, 4 GB
memory standard
Key prerequisites
Monitor
Planned availability date
March 15, 2011: System x3500 M3 - 7380
Description
Related options
IBM memory options
2GB (1x2GB, 1Rx8, 1.35V) PC3L-10600 CL9 ECC DDR3 1333MHz LP UDIMM
(49Y1403)
2GB (2Gb, 1Rx8, 1.35V) PC3L-10600R ECC LP RDIMM (49Y1405)
4GB (2Gb, 1Rx4, 1.35V) PC3L-10600R ECC LP RDIMM (49Y1406)
4GB (2Gb, 2Rx8, 1.35V) PC3L-10600R ECC LP RDIMM (49Y1407)
8GB 2Rx4 2Gbit PC3L-10600R LP RDIMM 1.35V Capable (49Y1397)
8GB 2Rx4 2Gbit PC3L-8500R LP RDIMM 1.35V Capable (49Y1398)
16GB (2Gb, 4Rx4, 1.35V) PC3L-8500R LP RDIMM (49Y1400)
2 GB (1 x 2 GB, 2R x 8, 1.35V) PC3L-10600 CL9 ECC DDR3 1333MHz LP RDIMM
(49Y1392)
2 GB (1 x 2 GB, 1R x 4, 1.35V) PC3L-10600 CL9 ECC DDR3 1333MHz LP RDIMM
(49Y1393)
4 GB (1 x 4 GB, 2R x 4, 1.35V) PC3L-10600 CL9 ECC DDR3 1333MHz LP RDIMM
(49Y1394)
IBM processor options
Addl Intel Xeon Processor E5603 4C 1.60GHz 4MB Cache (81Y5942) 1066Mhz
80w
Addl Intel Xeon Processor E5606 4C 2.13GHz 8MB Cache (81Y5943) 1066MHz
80w
Addl Intel Xeon Processor E5607 4C 2.26GHz 8MB Cache (81Y5944) 1066MHz
80w

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the IBM x3500 M3 and is the answer not in the manual?

IBM x3500 M3 Specifications

General IconGeneral
Form FactorTower
ProcessorIntel Xeon 5600 series
Processor CoresUp to 6 cores per processor
ChipsetIntel 5520
MemoryUp to 192 GB DDR3
ManagementIntegrated Management Module (IMM)
StorageSupports SAS, SATA, SSD
Hard Drive BaysUp to 8 x 3.5" or 16 x 2.5"
RAID SupportRAID 0, 1, 10
Network InterfaceDual Gigabit Ethernet
Expansion Slots6 PCIe slots
Operating System SupportMicrosoft Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware ESXi
