IBS BatchControl CTR 210 User Manual

Fitting and Installation
2.5.9. Digital outputs
The CTR210 / BGI210 has six digital outputs.
Terminal 26 + digital output 1
Terminal 27 - digital output 1
Umax = 36 V
Imax = 500 mA
Terminal 28 + digital output 2
Terminal 29 - digital output 2
Umax = 36 V
Imax = 500 mA
Terminal 30 + digital output 3
Terminal 31 - digital output 3
Umax = 36 V
Imax = 500 mA
Terminal 32 + digital output 4
Terminal 33 - digital output 4
Umax = 36 V
Imax = 500 mA
Terminal 34 + digital output 5
Terminal 35 - digital output 5
Umax = 36 V
Imax = 500 mA
Terminal 36 + digital output 6
Terminal 37 - digital output 6
Umax = 36 V
Imax = 500 mA
The control outputs are electrically isolated and passive. Please note the
potential direction of the outputs.
2.5.10. Potential equalisation
The PE must be connected to the PE terminal 38 and simultaneously on the
PE-screw.
10
