IBS BatchControl CTR 210 - Analog Input Pt100; Interface RS485; Analogue Output 1

Fitting and Installation
2.5.4. Analogue input Pt100
Each input can be provided with a Pt100 input module as an option.
Pt100-inputs are not voltage-free, i.e. the minus is at instrument ground
potential.
Terminal 1 + measuring input 1
Terminal 2 - measuring input 1
Terminal 3 + current output 1
Umax = 5,3 V
Imax = 2 mA
Terminal 4 + measuring input 2
Terminal 5 - measuring input 2
Terminal 6 + current output 2
Umax = 5,3 V
Imax = 2 mA
Terminal 7 + measuring input 3
Terminal 8 - measuring input 3
Terminal 9 + current output 3
Umax = 5,3 V
Imax = 2 mA
Temperature range: -200 °C to +800 °C
Error: < 0,1 % from end value
2.5.5. Interface RS485
Terminal 10 GND
Terminal 11 B
Terminal 12 A
Imax = 20 mA
2.5.6. Analogue output 1
The analogue output is not electrically isolated. The minus is at ground
potential.
Terminal 13 + current output 1
Terminal 14 - current output 1
Umax = 24 V
I = 4 - 20 mA
