iC-PV EVAL PV1M1
EVALUATION KIT DESCRIPTION
Rev A6, Page 2/9
OVERVIEW OF KIT ITEMS
Figure 4: Evaluation kit. Scope of delivery:
PV1M1 module, CR1025 battery,
diametric 4 mm NdFeB magnet,
BiSS adapter cable.
Figure 5: End-of-shaft application example
Figure 6: Application of evaluation kit, iC-MB3 iCSY MB3U-I2C has to be ordered separately.
